IEC 60884-1 Clause 19 | IEC 60669-1 Clause 17 | IEC 60998-1 Clause 15 Temperature Rise Tester

Product No: WS-1

Leave a Message

[wpforms id="9600"]
  • Description
  • The WS-1 Temperature Rise Tester fully complies with the requirements of IEC 60884-1 Clause 19 (GB/T 2099.1 Clause 19); IEC 60669-1 Clause 17 (GB 16915.1 Clasue 17); and IEC 60998-1 Clause 15 (GB/T 13140.1 Clause 15). It uses voltage and current to simulate the tested object (e.g., household appliance plugs, sockets, and connectors) under normal operating conditions to measure its temperature rise after a period of use.

    Specification:

    LISUN Model

    WS-1

    WS-2

    Test Stations

    8

    Test Current

    0~50A

    0~200A

    Test Voltage

    Less than 3V

    Timer

    Adjustable 0~9999s

    Adjustable 0~9999s

    Thermometer

    0~1,000℃ (Includes 8pcs K-type thermocouples)

    Standards

    IEC 60884-1 Clause 19 (GB/T 2099.1 Clause 19)

    IEC 60884-1 Clause 19 (GB/T 2099.1 Clause 19), IEC 60669-1 Clause 17 (GB 16915.1 Clause 17), IEC 60998-1 Clause 15 (GB/T 13140.1 Clause 15)

    IEC 60884 1 Clause 19

    LISUN WS-1 Temperature Rise Tester – After-sales Frequently Asked Questions (FAQ)
    LISUN WS-1 Temperature Rise Tester were in the market for more than 10 years, LISUN engineers service team already summary the most of the After Sales Questions and Answers in the above link. Please read it carefuly, you can solve the most of the problems by yourself if you have some questions while using the instruments. LISUN will be continue to update this pages and more FAQ can be found in this topic link.
