GNGPL-S3633

14 AWG Test Pin of UL 498:2017 Figure 136.2

Terminal Abuse Test The same flush and self-contained receptacle having a 5-15R,5-20R，6-15R,or 6-20R configuration used for the conductor insertion and retention test and the conductor push-in test are to be tested as described in this section. The test conductors used in the previous tests are to be removed from the receptacles using the wire release mechanism. Exception: For receptacles witho...
