Wire Abrasion Testing Machine

Product No: LS-B36

[wpforms id="9600"]

The wire abrasion testing machine is fully based on IEC 60227-1 Clause4.2.3, and is suitable for abrasion test of finished soft cables.

Specifications:

Fixed Shaft Diameter	40+0.3mm
Test Rate	Single direction 40 +1 times/min
Test Stroke	Up and down movement within a distance of 0.1 m
Weights	500 +5 g (3 pieces)
Test Count	0 to 999,999 times, presettable
Power Supply	AC220V+ 10%/50-60Hz
Working Temperature	0-40°C
Working Humidity	30%-90%
Equipment Dimensions	800x600x1000mm

IEC 60227-1 Clause4.2.3
